Woodman DX Seatpost
| Article number: | 012-01-01 |
| Availability: | In stock |
The Woodman Post DX Seatpost exemplifies precision engineering and proven durability. Machined from high-strength T6 aluminum, this post delivers a balance of minimal weight and robust reliability for both road and mountain bikes.
Its tapered tube design reduces weight where possible while retaining the strength needed at high-stress areas. The cradle-and-yoke clamp system accommodates 7×7, 7×9, and 7×10 mm rails, ensuring secure fitment for both carbon and metal saddles. With 25 mm setback, the DX provides ergonomic positioning for endurance comfort and pedaling efficiency.
Each post includes titanium hardware for corrosion resistance and reduced mass, and a 5.5 mm wrench for precise installation. Rigorously tested and race-proven, the DX represents Woodman’s dedication to high-performance alloy craftsmanship.
NOTE: Do not cut the seatpost. Clamping load is engineered for the unmodified post length.
| Diameter | 27.2 mm | 31.6 mm | |||
| Length | 250 mm | 350 mm | 250 mm | 350 mm | 400 mm |
| Weight | ~120g | ~152g | ~140g | ~182g | ~202g |
| Min. Insertion | 65 mm | 85 mm | 65 mm | 85 mm | 90 mm |
| Max Insertion | 90 mm | 190 mm | 90 mm | 190 mm | 215 mm |
| Offset | 25 mm | ||||
| Rail Compatibility | 7 x 7 / 7 x 9 / 7 x 10 | ||||
| Material | T6 Aluminum | ||||
| _____________________: | ____________________ |
| Material: | • T6 Aluminum / Titanium |
| Rail Compatibility: | • 7 x 7 mm / 7 x 9 mm / 7 x 10 mm |
| Min. Insertion: | • 250 mm - 60 mm | 350 mm - 85 mm | 400 mm - 90 mm |
| Clamping Area: | • 250 mm - 35 mm | 350 mm - 105 mm | 400 mm - 125 mm |
| Max Torque: | • |
| Saddle Offset: | • 25 mm |
| Rider Weight Limit: | • |
